Minimum Illumination

 0.5Lux (color mode), 0.1Lux (B&W mode)

Lens

Lens

3.6mm

Viewing Angle

Horizontal Angle75°;  Diagonal Angle 105º

IR-CUT

Φ5 4pcs color lights and 4pcs IR lights, Wavelength 850nm ，IR angle 90 °

Distance

IR distance 8m

Video

video format

H.264

Resulotion

(1920*1080),VGA(640*352)

Video compression

32Kbps-6Mbps, can self-defined, default is 4Mbps

Audio

Audio compression

G.711

Speaker

1W， 8Ω

Microphone

-52dB

Pan & Tilt

Pan & Tilt

Horizontal：355°，Vertical：120°

Protocal

TCP/IP,UDP,DHCP,P2P and so on

Wireless

 IEEE 802.11B/G/N

Wireless LAN Frequency

2.4G and 5G

Recording

Micro SD size

up to 128G

Format

AVI

Alarm

Input/output

none

Alarm notification

Push notification for iPhone/Android APP
Upload snapshot and alarm records to TF card (when insert Micro TF card）

Physical
Environmental

Power

220V E27

Frequency

50Hz / 60Hz

Operating condition

Temperature:-0～50℃,humidity:10%～90%

Material

Plastic (ABS)

Box

Color box and carton，50pcs/carton

Dimension

Product size：68*68*170 mm      （L*W*H）
box size：   104*88*182mm         （L*W*H）
Carton size：54.5*38.4*46 cm  （L*W*H）

Weight

Net weight：0.3kg/pc
Carton Weight：15kg （only for reference）

Accessories

Manuals, screws, bracket

soft

Os Supported

Android,iOS

Certificate

Certificate

ISO FCC CE
