Image Sensor

1/2.8" IMX415 CMOS

Min. Illumination

Color: 0.01lux @(F1.0),  0 lux with white light

Shutter Speed

1/10 s to 1/10,000 s

Slow Shutter

Yes

Day & Night

Colorful Filter

Digital Noise Reduction

3D DNR 2D DNR

WDR

120dB

3-Axis Adjustment

Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°

Lens

Focal Length

2.8 mm

Aperture

F1.0

Focus

Fixed

FOV

2.8 mm, horizontal FOV: 105°, vertical FOV: 56°, diagonal FOV: 125°

Lens Mount

M12

Illuminator

White Light Range

Up to 30 m

Smart Supplement Light

Yes

Compression Standard

Video Compression

Main stream: H.265+/H.265/H.264

Sub-stream: H.265+/H.265/H.264

H.264 Type

High Profile/Main Profile/Base Profile

H.265 Type

High Profile/Main Profile/Base Profile

H.265+

High Profile/Main Profile/Base Profile

Smart Feature-set

Smart Event

Human detection, Vehicle detection

Basic Event

Motion detection

Linkage Method

Trigger recording:  network storage, pre-record and post-record              Trigger captured pictures uploading: FTP, Email

Trigger notification: FTP, Email


Max. Resolution

3840×2160

Main Stream

50Hz: 20@FPS(3840×2160),30FPS@(3072×2048,2592×1944,2560×1440,2304×1296 )           60@FPS(1920×1080，1280×720)；

60Hz: 20@FPS(3840×2160),30FPS@(3072×2048,2592×1944,2560×1440,2304×1296 )           60@FPS(1920×1080，1280×720)；

Sub-Stream

50Hz: 30 fps (720 x 480,640 × 480, 640 × 360, 480 × 360,CIF)

60Hz: 30 fps (720 x 480,640 × 480, 640 × 360, 480 × 360,CIF)

Image Setting

Rotate mode, saturation, brightness, contrast, sharpness, and white balance adjustable by client software or web browser

SVC

H.264 and H.265 and H.265+ encoding support

Day/Night Switch

Day/Night/Auto/Schedule

Network

Network Storage

Support local storage and NAS (NFS, SMB/CIFS)

Protocols

HTTP, RTSP, DHCP, FTP, NTP,ONVIF,P2P, DHCP,SMTP,RTMP

Client

AJ_Client,AC18Pro,VideoLink

Interface

Communication Interface

1 RJ45 10M/100M self-adaptive Ethernet port

Built-in Microphone

YES

Built-in Speaker

No

Reset Key

NO

On-Board Storage

NO

General

Operating Conditions

-30 °C to +85 °C, humidity 95% or less (non-condensing)

Web Client Language

14 languages: English,Russian,German,Italian,Turkish, Korean,Japanese,Traditional Chinese,

Simple Chinese,Ukrainian,Portuguese,Croatian,Polish,Farsi

Power Supply

DC 12V 1A , Φ 5.5 *2.1mm coaxial plug power PoE(802.3af) Max.12W

Protection Level

IP67-Each Camera has been tested waterproof

Material

Front cover:metal,body:metal,bracket:metal,ring:plastic

Dimensions

Camera: Φ 126 × 98 mm (Φ4.96" × 3. 86")

Package: 127 × 127 × 124 mm (5" ×5" × 4.88")

Weight

Camera: 605 g (1.32 lb.)
